LEGEND 1/8" MXF NL IP BALL VALVE
Call for Availability
1/8" x 1/8", MPT x FPT, 250 PSI WSP, 600 PSI CWP, Lead-Free, Chrome Plated Forged Brass Ball, Forged Brass Body, T-Handle, Large Port, Ball Valve
Product Description
Specifications
| Actuation Type | T-Handle |
|---|---|
| Ball Material | CW510 UNS C28500 Forged Brass |
| Body Material | CW510 UNS C28500 Forged Brass |
| Connection Method | Threaded |
| End Connection | Male Threaded x Female Threaded |
| End To End Distance | 1.87 Inch |
| Handle Material | Steel |
| Handle Style | T-Handle |
| Lead Free | Yes |
| Manufacturer | Legend Valve |
| Manufacturer Name | Legend Valve |
| Manufacturer Part Number | 101-530NL |
| Nominal Size | 1/8 Inch |
| Package/Shipping Quantity | 20 |
| Port Type | Large |
| Pressure Rating | 600 CWP, 125 PSI WSP |
| Seat Material | TFM PTFE |
| Series/Model | T-900 |
| Size (Inches) | 1/8" |
| Stem Material | CW510 UNS C28500 Forged Brass |
| UNSPSC | 40141607 |
| UPC | 662545108308 |
| Valve Material | Brass |
