1-1/4" x 1-1/4", FPT x FPT, 150 PSI WSP, 600 PSI CWP, Lead-Free, Chrome Plated Forged Brass Ball, Forged Brass Body, Full Port, Lever Handle, Ball Valve
Product Description
More Information
Bottom Loaded Blowoutproof Stem with PTFE Packing Gland and Forged Brass Packing Nut; Self-Cleaning Forged Brass Ball is Chrome Plated to Resist Scale Build-Up; Lead-Free
Ball Valve; Type Gland Follower; Nominal Size 1-1/4 Inch x 1-1/4 Inch; End Connection Female Threaded x Female Threaded; End to End Distance 3.31 Inch; Ball Material UNS Alloy C46400 Chrome Plated Forged Brass; Body Material UNS Alloy C46400 Forged Brass; Stem Material UNS Alloy C46400 Forged Brass; Seat Material PTFE; Handle Material ASTM A283 Class D Steel; Port Type Full; Temperature Rating 250 Deg F; Pressure Rating 150 PSI (Saturated Steam), 600 PSI (Cold Working Pressure); Inclusions/Features UNS Alloy C46400 Forged Brass (End Adapter), AISI 1010 Steel (Handle Nut), ASTM B16 UNS C36000 Forged Brass (Packing Nut), PTFE (Stem Packing); Application Plumbing, Commercial, Industrial and Hydronic Professional; Applicable Standard ANSI/NSF 61/372, ANSI Z21.15, ASME B16.44, ANSI/ASME B16.33, UL 2J73, MSS SP-110, ANSI/ASME B1.20.1ISO 9002; Lead-Free
Specifications
Specifications
Ball Material
UNS Alloy C46400 Chrome Plated Forged Brass
Body Material
UNS Alloy C46400 Forged Brass
Connection Method
Threaded
End Connection
Female Threaded x Female Threaded
End To End Distance
3.31 Inch
Handle Material
ASTM A283 Class D Steel
Handle Style
Lever
Individual Item Weight
1.690 Pound
Lead Free
Yes
Manufacturer
Legend Valve
Manufacturer Name
Legend Valve
Manufacturer Part Number
101-066NL
Nominal Size
1-1/4 Inch x 1-1/4 Inch
Package/Shipping Height
8.800 Inch
Package/Shipping Length
16.100 Inch
Package/Shipping Quantity
36 per Case
Package/Shipping Width
13.100 Inch
Port Type
Full
Pressure Rating
150 PSI (Saturated Steam), 600 PSI (Cold Working Pressure)
