Compact Design for Tight Areas; Factory Pre-Assembled; Fully Automatic Operation; Quicktree® Technology Allows Quick Inspection and Removal of Float Switch without Disconnecting the Plumbing; Integrally Molded Rubber Gaskets for a Superior Gas-Tight Seal; Oil-Filled, Hermetically Sealed Motor with Thermal-Overload Protection; Corrosion Resistant Polyolefin Basin with Molded-In Connections; Maintenance Free, Permanently Lubricated Sealed Bearings
Drain Pump; Type Automatic, Compact; Inlet Size 1-1/2 Inch; Discharge Size 1-1/2 Inch; End Connection Female Threaded x Female Threaded; Basin Capacity 4.3 Gallon; Basin Dimensions 13-3/4 Inch Width x 11-1/8 Inch Height; Flow Rate 38 GPM at 5 Foot; Discharge Head 21 Foot; Casing Material Polymer; Shaft Material Stainless Steel; Basin Material Polyolefin; Housing Material Deep Finned Powder Coated Aluminum; Impeller Material Polymer; Impeller Design Vortex; Warranty 3-Year; Shaft Seal Details Engineered Double Lip Seal with Stainless Steel Spring; Solid Size 3/8 Inch; Vent Connection 1-1/2 Inch Female Threaded; Power Cord Length 10 Foot; Power Rating 1/3 HP; Input Supply Rating 115 Volt AC 60 Hertz 1-Phase 5.2 Amp; Speed Rating 3450 RPM; Temperature Rating 104 Deg F (Liquid Continuous), 266 Deg F (Stator), 221 Deg F (Thermal Overload); Motor Type Oil Filled Permanent Split Capacitor, Class B Insulation and NEMA B Design; Inclusions/Features Power Cord, Grounded Plug, Factory Pre-Assembled; Application Bar Sink, Laundry Tray, Dehumidifier, Utility Sink and Gray Waste Water Drainage; Applicable Standard UL, CSA (Canada and US), SSPMA; Finish Powder Coated; Locked Rotor Current Rating 8 Amp; Stator Winding Class B
Specifications
Specifications
Basin Capacity
4.3 Gallon
Basin Dimensions
13-3/4 Inch Width x 11-1/8 Inch Height
Basin Material
Polyolefin
Casing Material
Polymer
Discharge Head
21 Foot
Discharge Size
1-1/2 Inch
End Connection
Female Threaded x Female Threaded
Flow Rate
38 GPM at 5 Foot
Housing Material
Deep Finned Powder Coated Aluminum
Impeller Design
Vortex
Impeller Material
Polymer
Inlet Size
1-1/2 Inch
Input Supply Rating
115 Volt AC 60 Hertz 1-Phase 5.2 Amp
Manufacturer
Liberty Pumps
Manufacturer Name
Liberty Pumps
Manufacturer Part Number
404
Motor Type
Oil Filled Permanent Split Capacitor, Class B Insulation and NEMA B Design
Power Cord Length
10 Foot
Power Rating
1/3 HP
Shaft Material
Stainless Steel
Shaft Seal Details
Engineered Double Lip Seal with Stainless Steel Spring
Solid Size
3/8 Inch
Speed Rating
3450 RPM
Temperature Rating
104 Deg F (Liquid Continuous), 266 Deg F (Stator), 221 Deg F (Thermal Overload)
